Sunday at the reloading bench
« on: May 08, 2012, 07:52:14 PM »
Loaded up a few rounds Sunday and for some reason took a few pictures while doing it. I was reading Jim’s post under “Very tight bolt cycling” and it turned into some reloading stuff and thought I would use the pictures to make a post on some of the things I do when reloading.

Here is my reloading bench and Ed and Reggie will testify it is really that cluttered.
visitors can't see pics , please register or login


First thing starting out someone needs good references and here are a few of my most used loading books.
visitors can't see pics , please register or login


Here are the tools most used and used during this loading.

 Flash hole cleaner, brass cleaning brush, Inside outside case mouth deburer, Pocket primer deburer cleaner,OAL case trimmer
visitors can't see pics , please register or login


Lee hand primer
visitors can't see pics , please register or login


Scale and powder trickler
visitors can't see pics , please register or login


Case trimmer and neck turner
visitors can't see pics , please register or login


Case lube
visitors can't see pics , please register or login


Loading trays
visitors can't see pics , please register or login


Lee powder measure.
visitors can't see pics , please register or login


First I separate all my brass by head stamp.
visitors can't see pics , please register or login


Take one lot and spray with One shot lube
visitors can't see pics , please register or login


Run through sizing die
visitors can't see pics , please register or login


Deburr and clean primer pocket
visitors can't see pics , please register or login


Flash hole cleaner
visitors can't see pics , please register or login


Flash hole cleaned
visitors can't see pics , please register or login


Clean inside of case
visitors can't see pics , please register or login


Trim case to length
visitors can't see pics , please register or login


Deburr inside and outside of case mouth
visitors can't see pics , please register or login

visitors can't see pics , please register or login


Now I weigh each case and separate into lots of equal weights
visitors can't see pics , please register or login


Have primers for this load I have developed
visitors can't see pics , please register or login


Priming with Lee hand primer and from press
visitors can't see pics , please register or login

visitors can't see pics , please register or login


Check primer from face and side view
visitors can't see pics , please register or login

visitors can't see pics , please register or login


Now ready for powder.
visitors can't see pics , please register or login


Now that powder is in case and ready for loading I visually check from above all cases are loaded.
visitors can't see pics , please register or login


Bullet ready to be pushed into casing
visitors can't see pics , please register or login


Bullet loaded into case and then checked with caliper for proper depth
visitors can't see pics , please register or login

visitors can't see pics , please register or login


Factory crimp die
visitors can't see pics , please register or login


Bullets crimped in
visitors can't see pics , please register or login


All finished with this lot and ready to be labled and boxed for future fun.
visitors can't see pics , please register or login





easterncoyotes.com

ccp@finsandfur.net

Offline Bopeye

  • Platinum Membership
  • *
  • Posts: 5679
  • Hope and Change. How's that working for ya?
Re: Sunday at the reloading bench
« Reply #1 on: May 08, 2012, 08:46:21 PM »
Now that is awesome Richard. You need to put that up for someone interested in getting into reloading, but has no idea where to start or what to do. Very Nice!!!  :highclap:
Foxpro Staff Infection Free

Offline Hidehunter

  • FnF Life Member
  • ******
  • Posts: 1429
  • So hows that HOPE and CHANGE working out for you?
Re: Sunday at the reloading bench
« Reply #2 on: May 08, 2012, 08:55:53 PM »
Looks just like my process except most of the time I dont clean inside my casings.
Denver

visitors can't see pics , please register or login

Offline FinsnFur

  • Administrator
  • *****
  • Posts: 28384
  • Fins and Fur Outdoors
    • Fins and Fur Hosting
Re: Sunday at the reloading bench
« Reply #3 on: May 08, 2012, 09:37:49 PM »
 You got an ant on your table that followed me through it all.  :doh2:
Fins and Fur Web Hosting

   Custom built websites, commercial/personal
   Online Stores
   Domain Names
   Domain Transfers
   Free site maintenance & updates


 http://FinsandFurHosting.com

Offline Carolina Coyote

  • Silver Member
  • *
  • Posts: 2097
Re: Sunday at the reloading bench
« Reply #4 on: May 23, 2012, 07:35:31 AM »
Richard, Have you considered using A Sonic cleaner for the Brass, I bought one several months ago and very impressed with how well it cleans the inside of the Brass, I will post some pictures of an experiment I run on some very dirty Brass a couple of weeks ago. CC

Offline Carolina Coyote

  • Silver Member
  • *
  • Posts: 2097
Re: Sunday at the reloading bench
« Reply #5 on: May 23, 2012, 09:47:42 AM »
Here are some pictures I made of .223 Brass that I was experimenting with to check out the Sonic Cleaner and then Tumbling as the outside of the Brass was clean but not real shiny but again this was super dirty Brass, No hand cleaning or brushing was done.

This was how the Brass looked before Cleaning
visitors can't see pics , please register or login


This was after Sonic Cleaning and Tumbling
visitors can't see pics , please register or login


visitors can't see pics , please register or login


visitors can't see pics , please register or login


I did run the Sonic cleaner and Tumbler longer than normal on this Brass, I have seen where some guys have achieved bright shiney with just the Sonic Cleaner but so far all that I have cleaned I tumbled. My main purpose was to clean the ID and primer pocket with the Sonic  and as you can see it does a very good job. CC

Offline FinsnFur

  • Administrator
  • *****
  • Posts: 28384
  • Fins and Fur Outdoors
    • Fins and Fur Hosting
Re: Sunday at the reloading bench
« Reply #6 on: May 23, 2012, 09:00:37 PM »
Carl, you got a website for Sonic...I couldnt find anything but reviews and conversations.
Fins and Fur Web Hosting

   Custom built websites, commercial/personal
   Online Stores
   Domain Names
   Domain Transfers
   Free site maintenance & updates


 http://FinsandFurHosting.com

Offline Hidehunter

  • FnF Life Member
  • ******
  • Posts: 1429
  • So hows that HOPE and CHANGE working out for you?
Re: Sunday at the reloading bench
« Reply #7 on: May 23, 2012, 09:06:10 PM »
Looks like it does a Dandy Job!!
Denver

visitors can't see pics , please register or login

Offline Carolina Coyote

  • Silver Member
  • *
  • Posts: 2097
Re: Sunday at the reloading bench
« Reply #8 on: May 24, 2012, 06:46:46 AM »
This is the link for Sonic cleaning that I used, I bought my UltraSonic machine from Harbor Freight for less than $50.00, can't remember exactly what I paid  but they put them on sale from time to time. cc


http://www.6mmbr.com/ultrasonic.html
