majic smoke escaped

Started by BigB, March 10, 2007, 10:59:20 PM

Previous topic - Next topic

0 Members and 1 Guest are viewing this topic.

BigB

I was turning some more acrylic tonight, and all of the sudden, the motor bogged down on my Jet mini.  I could stop the motor by hand by grabbing the wheel on the headstock.  I shut it off, and looked around to make sure nothing was in the belt.  Everything looked fine.  Turned it back on, and the motor sounded funny.  And then it happened.  The magic smoke escaped from it. :confused:  I knew it was done for once the smoke escaped.

Anybody know the best place where I can get a spare part that is circled below?



Thanks,
Brian
hand call user primarily, but if you gotta use an e-caller, there ain't nothing that sounds better than a Wildlife Tech

FinsnFur

Man....good thing it didnt take the shop with it  :holdon:

Was the call ok?....no seriously?....this is acrylic were talking about. :sad:

I can't even tell what that thing is that's circled  :confused:
It looks like the inside of a cell phone with a couple little jumper leads on it from here  :shck: EY!...what'r you makin over there?
Fins and Fur Web Hosting

   Custom built websites, commercial/personal
   Online Stores
   Domain Names
   Domain Transfers
   Free site maintenance & updates


http://finsandfurhosting.com

BigB


I think it may be a flux capacitor??  :shrug:  :eyebrow:

Let's try this pic.    What ever the thing is, it is mounted on the side of the motor.  I took it off to see how bad the damage was.  I turned the lathe back on, and more smoke escaped.  It stinks really bad.  It must be mad at me for something. :wo:




hand call user primarily, but if you gotta use an e-caller, there ain't nothing that sounds better than a Wildlife Tech

FinsnFur

Oh yeah....that shot shows the call a little better. I think it'll be ok, considering the trauma it's been through   :whew:


..... :holdon: oh wait...yeah the capacitors  :eyebrownod: Heck it looks like they piggy backed that thing in there like they had a feeling it was gonna be a short ride.
Where was the smoke coming from?...that cover?
You might be able to replace the capacitors....but then again...what caused it?  :wo:
Fins and Fur Web Hosting

   Custom built websites, commercial/personal
   Online Stores
   Domain Names
   Domain Transfers
   Free site maintenance & updates


http://finsandfurhosting.com

studabaka

I don't know much about lathes, but it sure seems to me that the location of the motor is just asking for trouble and I'm guessing that it sucked acrylic dust into the housing and it didn't get along with the hot motor. I'm also guessing that you'll have to replace / rebuild / clean out the motor.

Wondering if there is a way to shield/duct/filter it so the air being used to cool the motor says clean  :confused:
"If your argument can only be made or expressed by putting someone else down, then it probably ain't worth spit." -- MicheGoodStone SA Pro Staff

THO Game Calls

This is a link to an old thread on the USENET News Group Rec.Crafts.Wooturning that explains everything  you need to know about your jet and the capacitor that burned up.  If you are lucky, you should be up and running in a day or so.

http://groups.google.com/group/rec.crafts.woodturning/browse_thread/thread/5d52e73014e7316c/524348228d7190e6?q=capacitor&rnum=1#524348228d7190e6


If you replace the cap and  it still does not work, here is a link for the conversion motor that will turn your mini into a variable speed mini

http://www.pennstateind.com/store/tclvskit.html

Finally, if no one in your area has thie capacitor, let me know.  I have a Jet repair facility about 30 miles from me.  I can give them a call and see if they have it or can get it and how much.

AL
THO Game Calls
www.thogamecalls.com

Become one of 'The Hunted Ones' with a THO Game Call
Handcrafted Collector Quality - Field Proven Results

Bopeye

I use to watch the magic smoke myself..........can't remember much about those days though.
I found the cause......quit a few minor habits and the magic smoke disappeared.......... :eyebrownod: :innocentwhistle:
Foxpro Staff Infection Free

THO Game Calls

 :roflmao:   Too funny Bopeye.

AL
THO Game Calls
www.thogamecalls.com
Become one of 'The Hunted Ones' with a THO Game Call
Handcrafted Collector Quality - Field Proven Results

Hawks Feather

Bopeye,

When you did that did your eyes look like your dog's eyes in the picture?

Jerry

Bills Custom Calls

BigB does this mean I have to wait a little bit longer on my call


Bill
http://www.billscustomcalls.net

Home of the Triple Surface Pot Call

BigB

Quote from: bnccont on March 11, 2007, 02:44:56 PM
BigB does this mean I have to wait a little bit longer on my call

Bill, you must have some pretty good eyes to see that coco dust amongst all of that acrylic.  The glue is drying right now on your call. :innocentwhistle:

Brian
hand call user primarily, but if you gotta use an e-caller, there ain't nothing that sounds better than a Wildlife Tech

Bopeye

Quote from: Hawks Feather on March 11, 2007, 12:56:08 PM
Bopeye,

When you did that did your eyes look like your dog's eyes in the picture?

Jerry

Yepper............I haven't done it since Sept. 11, 1994.........it would probably kill me now..... :eyebrownod:
Foxpro Staff Infection Free

Bills Custom Calls

Really I was only Joking with you BigB  The call that you have made for me will do fine  :eyebrow:

Bill
http://www.billscustomcalls.net

Home of the Triple Surface Pot Call
