LIGHTS FOR HUNTING

[watchmaker]

THE UTG BARREL MOUNT



Hi guys,
For  those  wanting  a barrel mount for a flashlight or laser, I have had good
results with the UTG barrel mount.
Initially  purchased  for  an  AK rifle, I found out that it can be mounted in
other rifle barrels, for example, it fits perfectly in a .22 rifle and also in
a Mini 14 I have.

It is a tri-rail mount with three Picattiny rails that will also accept Weaver
style  rings.  My  model is the #2 mount which have two slots; the UTG is also
available  with  five slots that will accommodate the red dots scopes that are
in the market.

Picture of the UTG # 2


                                                                                ]

Another view






The UTG fully loaded with two TACM III tactical lights (one with a red filter)
and a laser.





The UTG is sold by Cheaper than Dirt and I imagine others places that cater to
tactical rifles. Just look in their catalogue in the AK accessories page.

Cheers

Watchmaker

[FinsnFur]

Now I like that

[Hawks Feather]

Jim,

Do you think he could make a model that would fit a Bud can?

Jerry

[FinsnFur]

  wouldnt be necessary. Your always aiming for the same spot when you pull up on that can. It's more of a routine or form

[coyotehunter_1]

Jim,
Do you think he could make a model that would fit a Bud can?

Bud light?

[Bopeye]

Jim,
Do you think he could make a model that would fit a Bud can?

Bud light?

OHHHH CHET!!!  :roflmao: :roflmao: :roflmao:

[watchmaker]

VERY INTERESTING ARTICLE BY JAMES MAURER
ON THE BRIGHTEST LIGHTS IN THE WORLD
THAT YOU CAN GET OVER THE COUNTER.

THEY ARE ALL THERE
THE TORCH, THE POLARION, THE BOREALIS,
THE SUNFORCE, ETC.

READ IT IF YOU ARE INTERESTED IN LIGHTS

http://www.jamesmaurer.com/worlds-brightest-flashlight.asp

CHEERS

[watchmaker]

REMOTE SWITCHES
WITH PRESSURE PAD

Hi guys,
I have been using remote switches in my tactical lights that are mounted in rifles,  shotguns, and bows, for quite a few years now.
The most effective of them are the ones with a direct connection to the solder pad that touch the battery (no spring), like the ones in the TACM III tactical lights.
The reason that they are more effective is that they don't rob the system of any voltage (in the way of internal resistance) as do the ones with heavy springs.

Internal resistance is the name of the game, some of them, for example the TAC STAR pressure switch, can really make a bright lamp like the P-60, looks dim and murky, due to too much internal resistance in the design of the tail cap.

THE TAC STAR REMOTE SWITCH



A good one that I have used for years in mounting lights on my friends' bows and rifles, is the G&P tail cap with remote.  Its design is quite good and the internal resistance is low, but it is not designed for pump shotguns as the cord is just straight and not curly.

THE G&P REMOTE SWITCH



A very good one that I discovered recently is the Aimshot curly cord remote, the spring is copper and quite light and it seems to have very low internal resistance.
I discovered the Aimshot in Cheaper Than Dirt catalogue and at a very good price ($14.97) and it has become my favorite.
I just used one in a Pelican M-6 tactical light and mounted it using a UTG Tri rail mount in an AK rifle, it does the job well.

THE AIMSHOT REMOTE SWITCH



Cheers

Watchmaker

[iahntr]

Thanks for the info.
I never thought about different switches having different
resistance and causing the light to be dimmer.

[watchmaker]

THE 200 LUMENS BATTLE

There are now a number of aftermarket lamps for the popular series of Surefire lights.
They will fit the Surefires series: 6P, C, Z, D, G, and maybe others.

I just received a new one that claims 290 lumens and is called a Cree R-2 (it's supposed to be even more powerful than the Cree Q-5).
I decided to do a shoot out with an assortment of lights that I have in the 200 plus lumens class. That way the members can see how they perform against each other.

Run time was not measured for lack of time and because I am running short on 123's batteries. The bigger lights, namely the Surefire M-4 with the MN60 lamp (225 lumens for 60 minutes on four 123's disposable batteries) and the Bear Cub from Black Bear Flashlights (220 lumens for 90 minutes on rechargeable Li Ion batteries) are big throwers and with them you can see clearly objects 120 and 150 yards away.

On the other hand the small reflectors of the Surefires G-2, Centurion 2 and Fenix T-1 are dispersing all those lumens close by, creating a great flood.
Those pocket lights will be great to use as tactical lights by law enforcement personnel, and especially good at clearing houses, while the Surefire M-4 and the Bear Cub will make great lights for car, truck and the open spaces.

The literature of the Fenix states that it's good for 200 yards, it will probably make a reflective target like a stop sign glow at that distance, but it would hardly  illuminate any other object. My perception from trials I made, is that this light as well as the others LED's can't be count to illuminate (poorly) objects beyond 60/70 yards.


In any case, a lamp upgrade if you own a Surefire pocket light, is a good idea as any of them are more powerful than the stock incandescent lamp of 65 lumens or the stock LED lamp of 80 lumens.


The lights as they appear in the picture are, from left to right:


Surefire M-4 MN60 lamp 225 lumens for 1 hour (running on four 123's batteries)
Bear Cub 220 lumens for 90 minutes, rechargeable
Surefire G-2 in yellow. It is 65 lumens for one hour with the stock P-60 lamp
Surefire G-2 in black, Lumen Factory lamp incandescent of 160 lumens
Surefire G-2 in green, Cree Q-5 by Deal Xtreme, 200 lumens
Surefire Centurion 2 in Jungle Camo, 290 lumens (claimed) with the Cree R-2 lamp
Fenix T-1, 225 lumens using a Cree Q-5 lamp




And now the pictures, target is 20 yards away, watch also the amount of side spill as well as the throw.

SUREFIRE M-4 DESVASTATOR 225 LUMENS



BEAR CUB RECHARGEABLE 220 LUMENS



SUREFIRE G-2 YELLOW 65 LUMENS



SUREFIRE G-2 BLACK LUMENS FACTORY 160 LUMENS LAMP



SUREFIRE G-2 GREEN, DEAL XTREME LAMP CREE Q-5 200 LUMENS



SUREFIRE CENTURION 2, CREE R-2  290 LUMENS (CLAIMED)



FENIX T-1 CREE Q-5  225 LUMENS





One word of caution with high intensity LED lights: most are not thermally regulated and they will suffer from their own heat if used for an extended period. They will get very hot and the tint will change. Short use of 5 minutes or less is recommended, especially in lights like the G-2 that has a plastic body and head.

All metal flashlights like the Surefire 6P are better at dissipating the heat, and in them a few more minutes of constant use can be achieved before the heat will damage the module.
The big heavy head of the Fenix acts as a heat sink, and this light can manage to run much longer without the heat affecting the module.

Besides, the Fenix has a second setting that will run the light at 60 lumens for 10 hours.
So, if you already have a Surefire you want to upgrade, the aftermarkets lamps are great.
If you need a new light look at the Fenix line.

If you need a truck, open spaces light, the Bear Cub is a great value as it is rechargeable and very bright as well as a 150 yards thrower.

Cheers

[Todd Rahm]

Nice informative post WM. I'd like to put a set up on my rifle as a back up incase my spotting light goes out at night, or for quick calling trips where I don't take in the big spotter.

Right now I have to SureFires, one for sure is the 6P the other I'm not sure but looks similiar to your camo one, except mine is black. I'll check into that switch and the Fenix line.

[watchmaker]

Todd,
The jungle camo is a Centurion II Surefire, it has a clip, consequently it will not fit a 1" ring.

But the 6P is ideal for mounting in your rifle with any Weaver style 1" ring and a Weaver base or Picattiny rail.
If you put the new Cree R-2 aftermarket lamp in there and a Aimshot remote switch, you will be all set for coyotes at short distance.

Cheers
Watchmaker

[watchmaker]

Merry Christmas to all

[watchmaker]

TERRALUX LIGHTSTAR 220
FLASHLIGHT

For the last two months, I have been using one of the Terralux Lightstar 220 lumens flashlights, which runs on two AA batteries.
This light has two settings on the click-tail cap; the first setting clicks on the light and emits 220 lumens for 1.5 hours.
The second setting of 100 lumens for 6 hours is accessed by softly pressing the rubber button switch.

The LED is a Cree RXE Q-4 and is controlled by a microprocessor for a constant light output.  When battery juice is running low, the LED will flicker to let you know that is time for new batteries.
The unit comes with two Energizer AA batteries, a lanyard and a soft nylon holster.  At an even six inches long, the light is quite portable and also features a clip to attach it to your belt or waistband.




It is very similar to the popular 3 watt 80 lumens Ray-O-Vac Sportsman Xtreme (but is slightly longer as the click tail cap needs more room for the mechanism), and the head is smaller with a small orange peel reflector.

Due to the small reflector the beam throws quite a flood despite the 220 lumens figure.  Small reflectors don't really have much throw no matter how many lumens you make the light puts out. However, it is quite adequate for most chores inside a house and practical, too, for walking the dog or a walk in the woods.

LIGHTSTAR AT 20 YARDS WITH THE 220 LUMENS




LIGHTSTAR WITH THE 100 LUMENS SETTING






The really nice thing about these lights are that they are very inexpensive to feed as they use common AA batteries. As I use rechargeable AA batteries in all my lights, it is even more inexpensive to use.
The dark green anodized body is quite resistant to scratches as the light is still like new even after a couple months of sharing my pocket with keys and coins.

Cost of the light varies depending where you buy it, but it is around $35 to $40 USD; your best bet is to Google it to see who has a special on it.
I like this light to the point of recommending it to anybody that is looking for a light with these characteristics.  The light is as good as the Ray-O-Vac Sportsman with the added power of the 220 lumen setting.
Cheers.
Watchmaker

[iahntr]

Looks like a nice one too. Thanks for puttin up your reviews.
Sent ya a pm with a couple questions for ya.
Scott

[watchmaker]

WHEN A LUMEN IS NOT A LUMEN

A lumen is not a lumen when somebody intends to throw a big bunch of them out of a small reflector the size of a dime or nickel. At least it seems to be that way.
It used to be easy to tell the power of a light by the lumens figure, not anymore. You could be an experience user of lights, say a policeman that had used for years a 200 lumens Magchager and is well acquainted with its capabilities. Now he reads about this small light the size of a thumb that also outputs 200 lumens and is all excited to get the new marvel.
He does and is promptly disappointed because the small light seems to throw a good amount of light, but all close by, and is nothing that can compare with his duty Magcharger that can illuminate objects at 100 yards.

Besides emitters in the 200 lumens bracket can kill themselves with the heat that they produce when they are used in small lights with poor heat sinking. It is mostly a novelty thing and it should be used with caution. Some of them come in lights with multiple settings, and that is fine when the literature advice you to use the 200 lumens sparingly, and you follow that advice.

To illustrate the point, here are a couple of pictures of beam shots at 20 yards, you can clearly see the superiority of the Bear Cub (reflector size 2") over the Lightstar 220, (reflector the size of a dime)  even when both lights are rated at 220 lumens.

LIGHTSTAR 220 LUMENS AT 20 YARDS



BEAR CUB 220 LUMENS AT 20 YARDS




Some manufacturers wishing to quote big numbers are now putting clusters of these small reflectors on duty size flashlights. Mind you these clusters that are from three to four are still all small reflectors with limited throw.
So, somebody putting a cluster of four reflectors in a big head can claim 800 lumens, but you know better now, knowing that those 200 lumens for each reflector are not really behaving like real lumens!

Unfortunately I don't have one of those lights to prove the point. But I can get my own cluster of lights in the 200 lumens bracket, and demonstrate by picture what can you expect.
I have here two of the Lightstar220 lumens, plus a Fenix P3D of 205 lumens and an Ultra Fire with Rebel emitter of 200 lumens, all of which together in a cluster will throw the figure of 845 lumens.
The opposite number is a Black Bear 720 lumens flashlight, a light that is 10" long and weights 24 oz. and uses a 2" reflector that can throw several hundred of yards with a strong white light.

HERE IS THE PICTURE OF THE CONTENDERS



The distance for both beam shots is in this case 35 yards to the target (The no trespassing sign tacked in the tree). The camera is 20 yards from the target.

CLUSTER OF REFLECTORS 845 LUMENS




BLACK BEAR 720 LUMENS ONE REFLECTOR 2"



Observe how the beam of the 720 lumens light travels beyond the range of the cluster lights, illuminating objects that the cluster lights are not capable of showing.
So, if you are in the market for a new light, this use of small reflectors in clusters to boost lumens figures is something you should be aware off.

Cheers

Watchmaker

[iahntr]

Interesting. Thanks again.
They should have some sort of rating for distance.
Would candlepower be the closest rating?
Of coarse most flashlights don't have a candlepower rating.

[watchmaker]

Many lights have both, lumens and candlepower.

Lumens are the total light emitted by the source.
Candlepower are the measure of intensity at the center spot

Candlepower favor BIG reflectors and is used mostly in spotlights as the numbers are impressive. (1 million  2 million etc)

Magcharger 40,000 candlepower, 200 lumens
Ultra Stinger, 75,000 candlepower, 295 lumens
Borealis, two million candlepower, 1050 lumens

Cheers
Watchmaker

[Hawks Feather]

Watchmaker,

Do you know anything about these?

http://www.all-battery.com/tenergypremiumledflashlight.aspx

My assumption is that that they are made by someone else and Tinerygy just puts their name on it.

Thanks,

Jerry

[watchmaker]

Jerry,
Most of the Chinese lights are junk, I have a few that didn't work out of the box. (tail cap and contact problems).
Some are good as is the Fenix line, Olight and perhaps others.

It is a chancy thing when you order a light if is going to please you, I have had problems also with customer service.

Except for the brands mentioned above, I stick with USA made for reliability and customer service.

Watchmaker
