LIGHTS FOR HUNTING

[watchmaker]

Hi guys,
I have a bunch of lights and I had this idea of taking beam shots so the members can see how they compare with each other.
Stop me if you find the post boring.
cheers


LIGHTS FOR HUNTING



This post will try to show how different lights used for hunting compare with each other, and will clarify the difference between the lumen ratings used in Luxeon (LED) lights and incandescent lights.
In short, I will show (through pictures) how Luxeons lack definition when used at increased distances.

I have maintained for a long time that LED Luxeons don't have the range over the incandescent to really be helpful for general hunting. They are excellent lights to use inside the house; their beams are very clean, white and with substantial flood, and in the average house, that is all you need. However, when taken outside to the backyard, woods, or large structure and the distance to the target is 25 yards or more, they lack definition (as they lack the red spectrum of light), and their poor penetration of fog or rain makes them inefficient to clearly identify what you are seeing at that distance.
Moreover, when the subject being illuminated is an animal with a light-drinking fur (depth of texture), the blending effect of the LED's (against the background) will cause the observer to lose perspective.


LOW LIGHT FOR WALKING IN THE WOODS


Hunters that have used the Fenix LOP (1 AAA) consider this light ideal (except for the lack of a clip). Another favorite is the ARC AAA. These lights can be held in the mouth without any discomfort.

Fenix has put out a bigger light (1 AA) with two stages output, and the lower output will be also ideal for projecting a soft LED beam that will aid in walking the woods in the pre-dawn blackness when going toward your stand, (perhaps following a trail of cat-eyes) at this time, it is necessary not to pollute the area with more light than what is absolutely needed.
Some hunters that know the terrain well, prefer to use a red filter over the light, as is well known that deer and others animals cannot see red light.


THE BELT LIGHT

Those same hunters want to have a good light on their belt. Some prefer the two cell 123's lights like the Surefire 6P, G2, or C-2 for their better flood beam over the more tightly focused Streamlight Scorpion, TL-2 and Night Fighter II.
They look for a run time of one hour and an output of 65 lumens.
Some opt for more intense lights like the Surefire 9P or the C-3 with their 105 lumens and one hour run time.
The Streamlight TL-3 is a little too tightly focused for a belt light but it will do fine at the longer distances were the bigger lights shine.
In LED form (Luxeon V), the Surefire L-4 is a good contender due to the excellent flood light that it puts out at medium range, however it lacks the throw needed for more distance illumination.

The main thing is that the hunters want to avoid losing precious seconds by panning a light when in the woods. That is why the Surefires are preferred over the tightly focused others brands, because they have special reflectors that diffuse the light into a bigger flood pattern.


THE CAR LIGHT

Some hunters  wear a light holder in their belt (a plastic and leather ring). On exiting their cars, they slip in the ring one of the powerful rechargeable lights, most commonly the Magcharger (200 lumens) or the Ultra Stinger (295 lumens) and some even  a Borealis 1050 lumens mega light.

Those are ideal lights for search for wounded game, search and rescue of lost partner, signaling at long distances and using them as spotlights after the hunt. Being rechargeable, they are always used with a maximum run time (taken out of the charger at start of the day, a thing that you can not do with 123 batteries unless you are willing to dump half-used batteries at the start of every day of hunting.

Their large diameter (2 inches) reflectors put more light at a longer distance than any of the belt lights. Even though some of the belt lights approach 200 lumens, they do it with reduced run time and much reduced throw, due to their small diameter reflectors.
A Magcharger will put a spot of light at 150 yards, as will the Ultra Stinger and a Borealis has the capability of illuminating the whole road for 250 yards.


Lets start with the popular Surefire G-2 (or 6 P) at 65 lumens, the target is the 8 by 12 tool shed at 30 yards.
We are going to pit the Surefire G-2 65 lumens $35.00 against the Surefire Digital Lumamax L-4 (also 65 lumens and with a price tag of $160.00).

Surefire G-2 65 lumens



Surefire L-4 Luxeon V, LED, 65 lumens



And now we are going to pit the Surefire 6 P with the P-61 120 lumen lamp (20 minutes run time) against the best Luxeon LED thrower that I have (similar to the cree LED).
This is a Mc Gizmo PR T head with a TWOJ bin Luxeon doing 120 plus lumens.

Surefire Centurion C-2 (same as the 6P) with the P-61 lamp, 120 lumens.



And the PR T with TWOJ bin Luxeon, (LED) @ 120 lumens



And now we are going to show a belt light of 200 lumens (The Surefire Centurion III with the P-91 lamp, 200 lumens, 20 minutes run) and three cars' lights of 200 lumens plus and beyond.

Surefire Centurion C-III, 200 lumens P-91 lamp.



And here the Magcharger also 200 lumens, with its bigger reflector and tighter focus will throw the light at 150 yards, while the Centurion III range will stop at 45 or 50 yards.

Magcharger 200 lumens (40,000 candlepowers)





And here is the Ultra Stinger, the most powerful of the rechargeable from Streamlight with 295 lumens and 75,000 candlepower.



And now the BOREALIS, the light that has  the format of a 3 D (12 1/2 inches long) outputting 1050 lumens for 50 minutes.
This is similar to a two million candlepower spotlight





As I have over 200 lights that I have used at one time or another in my hunting expeditions, I am well familiarized with distinct situations that call for different lights and method of using them.
I have encountered a new one lately, that calls for following a wounded wild boar at night with a powerful pistol like the S&W 500 or a 454 Casull  and also a powerful light in the order of a Surefire M-6 (500 lumens) or a Borealis 1050 lumens.
For myself, I cannot think of another pursuit that could be more dangerous to life and limb, although I have a lot of respect for the young athletes that have tried it, I consider it too "Extreme" for my good health.

Hope I can do some more talking to the members about my second hobby after knife collecting, which is of course hunting at night and light usage.

Respectfully
Watchmaker

[watchmaker]

MORE LIGHTS FOR HUNTING


As a continuation of the first post and for whatever value it has, I am going to do some more shoot outs of a mix of popular Luxeon lights and incandescent ones.

The first order of things is to change the target area, to make it a little more interesting to my viewers.
Consequently I replaced the tool shed target with a deer and bear mount.
The deer head mounted on the tree is exactly 26 yards from my second story window from where the lights are shinning.
The bear head in the fence is only six more feet further away from the tree.

In the summer I have plenty of bushy cover in the area, but this time I had to be creative and cut and nailed to the tree and fence, some branches from a pine tree, not to hide the animals from view, just to provide a natural blending effect, like they were coming from a natural habitat.

The camera was placed twelve foot away from the tree (and eighteen feet from the bear) in a solid tripod, and the night  camera mode used (this mode shows in pictures the same light values that I am seeing with my own eyes).

The close proximity of the camera is for the viewer to see the target with clarity; if I were to place the camera 26 yards away the target will be awfully small.

Here it is the target area and  how it looks  in daylight.



And here are the contenders, but before I describe them, let me voice my opinion that some manufacturers of Luxeon lights label the output in lumens in quite a wild way.




From left to right:  # 1 Fenix L1P at about  40 lumens, # 2 Nuwaii Q III  at 75 lumens (yes, sure!) # 3 Surefire L-4 Digital Lumamax at 65 lumens (this is a Luxeon V which is quite a flood light but with little throw).

# 4 Streamlight Task-Light 2 L (two Lithium 3 volts batteries, high and low output,
Cost is about $77.00) This is billed at a High Flux Luxeon III. With 75 lumens, which I think is about right.

# 5 is the Streamlight Pro Polymer 4 AA with a Luxeon I,  billed as 40 lumens (3,500 candlepower according to the advertising) which I think is quite wrong, as it appears to me to have about 70 lumens or more, this light has a bigger and deeper reflector than the others lights and the beam is concentrated more than the others. This is a great light for the price of about $40.00

# 6, this is a PR T Luxeon III head done for me by master modder McGizmo, it is set on a Surefire E2e body and I am using two rechargeable 123's with a voltage of 4.2 volts in it.
This light is my best Luxeon III light and up to two years ago it was  pretty HOT STUFF, today the cree LED's are approaching it in intensity, although it has not been overpower by any other Luxeon, yet.
My friends told me I have two of the Integrated Sphere Spectotometers just above my nose, those spheres are telling me that this light makes 120 to 130 "real" lumens.

# 7, this is A Surefire Centurion II in black with the P-60 lamp (65 lumens) this represents all the others Surefires lights that use this lamp, G-2, 6P. Z-2. etc.

# 8, this is another Surefire Centurion II, but in Hard anodized, it wears the HOLA lamp. The P-61 with the output of 120 lumens for 20 minutes.

# 9 this is a Surefire Centurion III (3 cells) this is usually sold with the P-90 lamp that makes 105 lumens for one hour, but in this case is set up with the P-91 lamp for 200 lumens for 20 minutes, as you will see in the picture later, the floodlight effect is great at 26 yards. All those P's lamps start to lose range at about 45 to 50 yards, this is because the reflectors are fabricated to produce a good flood so police officers can clear houses with them.
I took this particular light out of my Remington 742 rifle, where it sits in the special quick detach mount in a Picattiny rail.

# 10, this is the BEAR CUB, this light weights 13 oz and measures 9 inches long, it works with two Lithium Ion computer batteries, and produces 220 plus lumens for 90 minutes. Thanks to the big and deep 2 inch mirror-like reflector, this light concentrates the beam like a laser and has a throw of 120 to 150 yards.
So the 26 yards distance is like child play for the Bear Cub and the light is so intense at the target that they had to close their eyes!

# 11,  (last on the left lying in horizontal position next to the Bear Cub) this light is a KL-1 head Luxeon I of three years ago, it is set up in a Surefire Outdoorsman body and the lumens output is no more than 20, consequently I decided to strike it out from the competition, there is no room in my stable for weaklings and I will present it to my nephew on his birthday quite soon.

And now let's go to the pictures:

Fenix L1P  (40 lumens) Luxeon I



Nuwaii Q III (advertised at 75 lumens in a website, which I don't believe) Luxeon III.




Surefire L-4 Digital Lumamax (65 lumens) this is very flood light and the lumens spread in a very wide area, so it cannot  be expected to have a good throw at 26 yards. (Luxeon V ~which are 4 of the one watt together)




Streamlight Task Light 2 L about 75 lumens on high, works on two 123's batteries and has two levels of illumination.  High Flux Luxeon III. About $77.00



Streamlight Poly Pro 4 AA Luxeon.  This light has a deep and bigger reflector, the Luxeon is  I, according to the manufacturer, is listed at 40 lumens, but to my eyes is doing about 75 lumens.
For the price of $40.00 this is a great light, and very battery friendly as it uses regulars AA.
I feed this light, rechargeable Nimhs AA of high current (Powerex 2700 mah) that hovers around 1.4 volts for weeks consequently it costs me nothing to operate it.





Mc Gizmo PR T head on Surefire body, Luxeon III, TWOJ bin,
My best Luxeon light putting out 120 to 130 lumens. This is a collector's item and was state of the art, less than two years ago.
I have found nothing new that can approach its power, except the new cree 7090 that is getting close.



Surefire Centurion II in black with the P-60 lamp (65 lumens for one hour)





Surefire Centurion II in Hard anodized with the P-61 lamp (120 lumens for 20 minutes)



Surefire Centurion III in hard anodized, with the P-91 lamp (200 lumens for 20 minutes) as you can see it is a great flood at 26 yards.





BEAR CUB running for 90 minutes on two computer Lithium Ion batteries, driving a Xenon Magnum Star  bulb for 5 cells pretty hard at 8.4 volts  at 220 lumens (which make it a very white light) with a reach of 120 to 150 yards, even surpassing the Ultra Stinger.



Best regards
Watchmaker

[watchmaker]

THE SUREFIRE E2E
here is one more:
As the Surefire E2e is a very common light in the bow hunting and gun hunting scene and also for law enforcement, here it is.


The little MN03 lamp (60 lumens for 75 minutes) in the E2e is a big performer, I like myself this little light a lot, and I think it qualifies as a tactical light to be used at close to medium range if the need arose.
The MN02 lamp can be substituted for more run time, as it is 25 lumens for 2 1/2 hours, I actually prefer this lamp for hiking  in the trails and other general chores, but I will use the 60 lumens lamp for blood trailing a deer or bear.

Red, blue and infrared filters are available from Surefire and vendors such as Cabela's. The red is used to walk in the trails or follow the cat-eye tacks when you go toward the stand in the pre-dawn darkness and don't want to pollute the woods with light, and the blue to bring up the blood drops in the leaves.

The E2e is 4 1/2 inches long and weighs at 3 .1 oz., is available in hard anodized type  III and will not scratch easily, but it can be rough on your pocket liner.  Other finishes are available sometimes. A tear drop bezel model is done in nickel plated and the wine light in regular anodized with a wine burgundy color.

Here is a picture of a few of the versions of the E2e.





And here is the beam shot at the same distance as the others above (26 yards) and the camera placed at the same distance (12 feet to the Deer head and 18 to the Bear head).




I can tell you that the light is fairly waterproof.  I don't have a pool to try it at a few feet, but it survived quite well in my 3  ½ gallon beer glass for several hours.



Kind regards,

Watchmaker

[Hawks Feather]

Watchmaker,

First off, welcome to Fins and Fur and I hope you enjoy it here.

Second, this is a FANTASTIC review of lights.  I have several, but keep wondering about what "this one" or "that one" would do.  After looking at this I have a pretty good idea what many will do.

Last, there is someone standing beside your barn.  I guess if you want to see what is REALLY out there, you need to use a bright light.

Jerry

[awh]

Cool write up. Welcome to FNF.
I'm like Jerry, I wondered about a few of them , now I know.Thanks for the post.

[KySongDog]

Welcome to FnF, Watchmaker!

Very good comparison on lights.  Very informative.  What do you think about the Surefire G2?  It seems to do a good job for the price.

Semp

[watchmaker]

Thank you guys for the welcome and the appreciation of my post.

Semp,
I like the Surefire G-2 a lot, it will put out 65 lumens with enough side spill to make the light useable even for law enforcement, the plastic case will not show scratches like the anodizing metal do, and the P-60 lamp is the same that is used in their more expensive military lights.

Watchmaker

[Hawks Feather]

Watchmaker,

I am just wondering if you test lights for a business, have stock in battery companies, or just really like lights.

Jerry

[FinsnFur]

I believe he sells them Jerry, if I remember correctly

Correct me if I'm wrong Watchmaker.
It's not a problem either way, your free to post them. The only rule is you post something besides the ads to shag the spamming image.

Also...if your not selling these or any lights for that matter, with all due respect I'd like to move this topic to the Reviews forum which is where more members will go when in the market for something and researching.
Weclome to the board

[watchmaker]

FinsnFur
Administrator.

Thank you for the welcome and the invitation to keep posting, I am sorry if I should have posted it on the review forum, you are welcome to move it.
This is a pet project of mine (as I have about 200 lights) to do beam shots so members can check how the popular lights compare with each other.
I don't sell the flashlights I posted in here, but I do built the rechargeable BOREALIS 1050 lumens flashlight, which is a specialized flashlight used mostly for law enforcement.

I had posted this LIGHTS FOR HUNTING in others forums that I contribute (mostly hunting and shooting forums) and it was taken so well by the members that I decided to share some more.

You are welcome to delete the thread if you think that it don't have any merit here.
I usually contribute with others threads like the one I will post about a binocular that I got recently.

Thank you very much for your invitation.
Best Regards
Watchmaker
a.k.a.
Black Bear

[watchmaker]

THE STREAMLIGHT SCORPION

I like the little Scorpion a lot, it is powerful (at 6,500 candle powers) light (at 4.4 oz) not too long at 4.9 inches and with a great feel in the hand thanks to the rubber boot that covers the body.
This rubber boot can be especially beneficial in the winter when others lights left in the trunk are too cold to hold without gloves.





The switch is momentary and click on, exactly as I want my switches; it is located in the back of the light and protected by the rubber boot.
The momentary works well, the click is in my case too difficult to operate with my big thumb and I have to click it with my index finger.
But it rarely that I use the click as this light can be used as a "tactical" light and the momentary mode is preferred when using it with a gun. (You don't want to drop the light "on" and that it will illuminate you or your partner, that is the reason to use the momentary).

The light uses two 123's batteries and run a xenon bulb for one hour, this xenon bulb is quite small, (a spare is located in the bulb holder inside the head) I will hate to have to change it in less than normal conditions, for starters you have to pry a cover from the bulb holder to access the spare, you will have a few small parts in your hands and you will need calm conditions and plenty of light to do the job properly.

For those situations I really prefer the big bulbs with reflector included of the Surefires' or even the smaller but easy to handle bulb of the E2e's.

Why I consider this so important? Well, the bulb is rated for 5 hours of life, which is extremely short.

I say I like this light, but it is really not rational because we have much better designs, for a tactical light. The little Scorpion will roll out on a table that is not perfectly flat, for lack of an anti-roll bezel. Surefires are much better in this department.

The beam can be adjusted by rotating the head (the filament of the bulb will go lower or higher inside the reflector), in reality I have the light set to maximum throw that will not show any artifacts and I don't twist the head at all because the quality of the beam will be spoiled by artifacts and black spots.
This light is good for throw considering the small reflector and the quality of the beam when set at near maximum throw is good, a nice round circle, (due to the short filament).

The lens is polycarbonate, I would like to see it changed to Pyrex, but that is my personal feelings that this light should deserve a better lens.
I bought mine two years ago from Cabela's and it cost me $38.00; I think that the price is right for a quality made American product.
The bulbs run about $6.00 each and I also consider them in price, they are so bright because they are overdriven (hence their short life of 5 hours).

I have seen a holster for the light made out of Cordura Nylon, but I haven't tried it and I don't know if is any issues in removing the light quickly, the rubber boot cause me trouble when removing the light from tight pockets (read Jean's) but is okay when the pocket is from s dress pants.
I also have seen filters made for this light in red, blue and yellow for those that would like to penetrate the deer's woods with a minimum of light pollution.

As always the beam shot are coming from 26 yards away and my camera tripod is in the same position, 12 feet from the deer and 18 from the bear.
I have also included as way of comparison the beam shot with the P-60 lamp out of a Surefire Centurion C-2 (read it also Surefire 6P, Z-2, G-2 D-2 etc).

SCORPION'S BEAM



P-60 LAMP FROM a Surefire Centurion II



You will notice that the beam of the Scorpion  is more concentrated than the P-60 lamp, making the target  clearer at this distance, for tactical situations at short range the P-60 lamp is better for the extra flood, it will be easier to clear a room with a Surefire without the need to pan the light to cover it all.

Cheers,
Black Bear

[FinsnFur]

I think you mis understood me watchmaker.
Your post certainly has merit so there no consideration in deleting it. And I'm aware of the lights you sell from me administrating another hunting site, but I'm fine with it.

There is no charge to advertise here if your a participating member.

With that said, if your not selling these lights I'm afraid the thread will get buried in this forum with Big Game hunting. And  the Review section of the board might be best.

Either way, I am not reprimanding you in any way, and I already feel like I've ruined your thread here. I would have PM'ed you but you cant reply anyway until you reach 25 posts.

[Hawks Feather]

Watchmaker,

I have the Scorpion and I really like it, but then again I am not using it in the tactical arena.  I actually have two of them and have one on top of the gun safe in case it would be needed and the other one I take whenever my wife and I go for walks and it is getting dark.  It is light weight to carry and works really well when you are wondering if someone is going to see you as you start across an intersection.  A quick blast at the driver helps them hit the brakes pretty quick.

Jerry

[watchmaker]

FinsnFur.
Love to see the thread in the Review section.
Thank you very much
Respectfully
Watchmaker.

[watchmaker]

CREE 7090 XR-E LAMP

JET-I (AA) MK IIX FLASHLIGHT


I had the opportunity to test briefly this flashlight a few days ago; since I just got to handle it for a few hours I will not call it a review, but just a little trial.

The light was actually passing by, my friend Luis from Spain had ordered from me a Borealis 1050 lumens and a Bear Cub 220 lumens flashlights, he also wanted one of Emilions' workbench JET-BEAM I MK IIX little lights that have multiple functions and are billed with a 100 lumens maximum power in the 1 AA version and with the extended tube for two AA batteries at 150 lumens.
So I had one ordered from Emilions and it arrived quite quickly, from Hong Kong to New York in just five days!

Physically, it is the size of my Fenix L1P light, (about 40 lumens) and it is very similar in shape and weight.
For those not familiar with these lights I have here a picture of them side by side.



By adding the extension for another AA, it is claimed that the maximum output is 150 lumens. Now that is a serious lumens output that we are taking about, so my main interest was to see if really the little light was going to reach that high.
Unfortunately I didn't have available any other comparable light, the closest that I had seem was my friend Fenix L2D that claims 135 lumens, but he was out of state, so the light was unavailable to me.

I have in my stable of lights, one PR T head (Pelican Reflector Turbo) that McGizmo made for me with a TWOJ Lumileds Luxeon III, which is a real screamer, going into the 130 lumens when pushed hard by two of the rechargeable 123's at 3.7 volts each.
This head is in an E2e body and is my favorite of the Luxeons lights I own.

The comparison to the little reflector of the Jet Beam will be unfair, as the Pelican reflector is much bigger in diameter and deeper, concentrating the light in a much tighter and intense beam.
The smaller reflector of the Jet Beam will tend to disperse the light beam in a more open pattern which will compromise the throw.

But here is a picture of the two lights side by side, so you can see how they look like, and how the Jet Beam is with the added 1 battery extension tube.



And here is a picture of the beam shot against the ceiling at a distance of 6 feet, the one on left is the Jet Beam I MK IIX



And after that, I took pictures of the beams shots at my customary 26 yards against the Deer and Bear heads.
If the picture of the beam shot of the Jet Beam doesn't look too impressive for the 150 lumens figure, keep in mind the terrible advantage in concentration of light that the Pelican reflector provides for my PR T 130 lumens light.

Beam shot with the Jet Beam 150 lumens (2 batteries, maximum power)



And here the beam shot with the McGizmo PR T head (130 lumens)



I can't close this account without telling my readers of the many features of the little Jet Beam light,
On the exterior the light is finished in hard anodized type III, the lens is Sapphire crystal and it comes with a set of extra switch covers, lanyard and a nice belt holster.

The circuit is 0.7V to 4.2V, after you click it on (Medium Brightness) soft touching the rubber switch will provide low brightness, maximum brightness and strobe, and one more touch will put the light in standby.

Waiting two seconds and clicking the light again will access the advanced mode with 10 levels of output, and five special functions including strobe SOS at 100 % and SOS at 5 % and others.

This seems to me, is the light to end all of the key chain lights and then some. As soon as my checkbook is recuperated from the ravages of uncle Sam, I am going to order one for myself.

I still think that for clearing a warehouse or a big yard, you need the longer distance reach of a good (in the 200 lumens bracket) incandescent light. When the factories start using the Cree 7090 with bigger reflectors, we will see the results, but I  myself  believe that the lack of the red spectrum in the Luxeons will always make them short distance lights and reduce the definition on the target; just look at the pictures that I have presented until now and see the performance of Luxeons even with the big reflectors of the Streamlight 4AA and the Task Light.

Kind regards
Watchmaker

[Nelson]

Watchmaker,
I've enjoyed reading your reviews.  I was wondering if you could comment on lights used for predator hunting at night?  Either gun mounted, head lights, or held by hand.  Thank you.

Nelson

[watchmaker]

Yes, for sure, I have scope and fore arm mounted lights as well as head lights, just give me a few days to take the pictures.
Cheers
Watchmaker

[Hawks Feather]

Nelson, thanks for asking; and Watchmaker, thanks for agreeing to do the post.

Jerry

[watchmaker]

Hi guys,
I did this piece for a hiking club I belong to. I thought that you guys could be interested. Just forgive me for the hiking flavor.

THE MOST POWERFUL FLASHLIGHTS
LIGHTS FOR TRUCK OR CAR


Hi guys,
Yes, I know that this has nothing to do with hiking, but most of us use car or truck transportation to get to the trail head and usually carry some form of a flashlight in the vehicle.
A powerful light can be a life saver in many instances, I well remember when driving up to the Adirondacks at 2 am in an empty 87 North at a point between exit 28 and 29 (North Hudson) some wild people in a truck tried to run us over into the shoulder of the road, my wife shinned a powerful light into their windshield and they desisted in the intent and actually braked hard and disappeared.
Maybe they though that only  police cars would have such a powerful light and that it was better to look for their kicks somewhere else; the case was that the light resolved the situation for us.

Then it was the time when we used it to illuminate the scene of and accident involving a deer and a poor woman in a compact car in a dark lonely side road, where blood and the insides of the deer were everywhere and the car was inoperable.

Calling by phone from New York City to a local in the Adirondacks to get our weather information I was told of a new ruse some bad guys were using to rob and hi jack cars in roads with poor traffic in the area.
The information came handy a few weeks later when in Boreas road near the junction with Tahawus road we were flagged by a guy in a truck with the head lights illuminating a dead dog in the middle of the road. at the time I was using a car I had bought from my neighbor the cop, it had a PA system and blue lights mounted in the vicinity of the radiator; we stopped short, illuminated the area with the two million candlepower of a Borealis flashlight and hit the blue lights and PA system telling them over the mike to stay were they where and to show their hands. The guy in the truck jumped inside and did a burning tire escape even running over the body of the dog, while his confederate in the bushes at the side of the road had just barely time to dive head first into the bed of the truck.

So I though that I will show the guys in the forums what a powerful light is since I have several of them with me.

HERE IS A PICTURE OF THE LIGHTS, FROM LEFT TO RIGHT:  Maglite 3 D,  Magcharger, Ultra Stinger, Surefire M-6 Guardian, and Borealis.



AND HERE A PICTURE OF THE BATTERY STICKS AND CARRIERS FROM LEFT: The 6 volts battery stick of the Magcharger, the skinny 6 volts  battery stick of the Ultra Stinger, the plastic carrier for the six 123's batteries of the Surefire M-6 and last the aluminum and Delryn 12 volts carrier of the Borealis 1050 lumens flashlight.





The Maglite 3 D is the most popular light carried by almost everybody in a truck or car. The 12 ½ inches of length and the thirty one ounces of weight make also a good impact weapon for emergencies, moreover, is the affordability of the light that can be obtained almost anywhere for less than $20, and, by the way, it is a quality instrument with tight tolerances and proudly still made in the USA.
So the Maglite 3 D is going to be our first test and beam shot, the light is quite waterproof to a good extend, my neighbor's kids use one to collect coins from the bottom of the pool in a game they have.
The Maglite 3 D output 39 lumens and runs on three of the popular D size alkaline batteries; it will run for an hour before the output drops to 20 lumens due to the sag that alkaline batteries exhibit under load.

BEAM SHOT OF THE MAGLITE 3 D  (39 LUMENS)



MAG Instruments also produce a powerful rechargeable police light called the Magcharger, www.maglite.com  this light is used by many police departments in the states and abroad; this light is the size and shape of a regular Maglite 3 D but with 2 rings of steel where the contacts for the charger are.
This light will output 200 lumens (40,000 candlepower) and I think that the price is about $120.00 a well built quality light of 12 ½ inch and a weight of thirty one ounces, it works with a 6 volt system on a stick of Ni Cads batteries; the charger will charge the light in 12 hours and as the Ni Cad batteries sometimes acquire memory, it is necessary to discharge it full and recharge to erase the memory in the batteries after using it for a couple of weeks.

BEAM SHOT OF THE MAGCHARGER (200 LUMENS)



The Streamlight Ultra Stinger is the most powerful offering from Streamlight, a well known police flashlight provider, The Ultra Stinger will output 75,000 candlepower, lumens figure is 295 lumens, it also works with a 6 volt system of rechargeable Ni Cad batteries, formed in a stick, the light is very popular with many police agencies and also recharges in 12 hours.
Police station across America have racks of Ultra Stingers in chargers waiting for the night shift to arrive, the light is a lightweight at 12 inches and 15 ounces, I think that the price is around $130 in the street as some lights can be bought at discount from the web.
The address for Streamlight is www.streamlight.com there they have the whole line of Stingers and other police and emergency services lights.

BEAM SHOT OF THE ULTRA STINGER  (295 LUMENS)




Our SWAT teams and Special Forces use for entry and to blind suspects a powerful military type flashlight called the Surefire M-6 Guardian. This light works with those powerful 3 volts Lithium batteries that are sometimes used in cameras, the flashlight uses six of them disposables batteries to run the light at 500 lumens for 20 minutes; after the 20 minutes you have to dump the batteries and get another six fresh batteries in the carrier, which is of not importance when the agency pay for the batteries, but to us civilians, dumping $12.00 worth of batteries after a 20 minutes run can get to be expensive.
This light was until recently the most powerful in the world, and Surefire sells a good quantity of them despite the tag of $400 USD.
I used one for a while in my car because it fits my glove compartment, as the light is shorter and lighter than the ones we have been discussing so far.
At 8 inches 14 ounces it is quite compact, but it will make a poor strike weapon although the powerful beam of 500 lumens will blind men or animal.
If you want more information on this light the address of Surefire is www.surefire.com


BEAM SHOT OF THE SUREFIRE M-6  (500 LUMENS)



My red rechargeable Borealis flashlight at 1050 lumens (two million candlepower) is the king of all the powerful lights and the most powerful flashlight in the world at this time.
It is made on the "host" of 3D, so replacement shells are easy available and inexpensive and the owner can replace a shell that have been scratched or dented for a mere $20 if he wishes, and in only 10 minutes transfer the special parts, (some of us take pride in good looking equipment).
This light is seen deployment with some members of the border patrol to illuminate the frontier in their quest for illegal immigration. The light can throw a powerful beam for hundred of yards and in a pinch it can be used as headlights or a landing light.
Police officers are acquiring the Borealis to use the same way that they have been using the Maglite and Magcharger, the tremendous light output makes it ideal for accident sites and traffic stops.
It uses a 12 volt system of rechargeable high current NINH batteries in a beautifully made Rolls Royce carrier, the batteries don't have any problem with memory and the new type of batteries used in this light can be away from the charger for more than a month before it needs to be topped off, and the recharging time of the light is only 90 minutes.
The run time of this light is 50 continuous minutes; it is 12 ½ inches long and weights 28 ounces. In test ran by the maker, the light was tortured and even shot with a .22 rifle without stopping emitting light. (As a video shows in the web site).
The light sells for $320 shipped directly from the maker, which is www.BlackBearFlashlights.com


BEAM SHOT OF THE BOREALIS  (1050 LUMENS)




I thought you guys will be interested to see all these lights in action, and I pointed them to a point in the fence next to the tree with the beams and camera shooting from a 35 yards distance, this is the longest distance that I have in the back yard

Although you can not take them in your night hikes (because of the extra weight) any of them will make a good addition to your car or truck gear, who knows,  maybe they can really help you out  of a tight situation like they did for me.

Respectfully

Watchmaker

[FinsnFur]

That is just too cool.
I think that last one is used for cleaning fence rows isnt it? Looks like quite the weed burner
